Factory Workshop Manual BSA A50 & A65 1969-70

Information

FACTORY  WORKSHOP MANUAL FOR THE A65 & A50 MODELS

Covers:

BSA A50 500cc & A65 650cc TWINS FOR 1969 TO 1970 MODELS

• A65FS FIREBIRD SCRAMBLER
• A65T THUNDERBOLT
• A65L LIGHTNING
• A50R ROYAL STAR  MODELS BOTH UK AND US MODELS.

THIS MANUAL HAS 8 PORTRAIT TYPE PICTURES OF THE BIKES COVERED.

THIS WORKSHOP MANUAL IS  AN EXCELLENT COPY OF THE ORIGINAL MANUAL WITH CLEAR BOLD PICTURES AND LITRATURE OF HOW TO DO VIRTUALY EVERY JOB SERVICING /RECONDITIONING/OVERHAULING ENGINE ,GEARBOX AND ROLLING CHASSIS INCLUDING ELECTRICS AND CARBURETTORS ETC.IT EVEN SHOWS YOU HOW TO STATICALY BALANCE THE CRANKSHAFT AND EVEN SHOWS CLEAR PICTURES OF A FRAME JIG FOR MEASURING VITAL ENLIGNMENT. IT SHOWS ALL MECHANICAL AND ELECTRICAL REPAIRS AND WHAT EXTRACTORS TO USE ALL TORQUE WRENCH SETTINGS AND DIAGRAMS OF THE VARIOUS COMBINATION OF SPROCKETS AND GEAR SETS TO USE AS WELL AS 2 DIFFERENT WIRING DIAGRAMS . AND FAULT FINDING SECTIONS ON THE ENGINE ,ELECTRICS AND CARBURETTORS THE MANUAL RUNS FROM 1969 TO THE END OF 1970 .

Coil bound copy

201 pages
